Polymax BS 5400/ EN 1337 - Bridge Bearing Grade Rubber Sheet

GBP 0.00
Not Available to Buy Online - Please contact us for more information.

 +44 (0) 1420 474123

Be the first to review this product

Quick Overview

Polymax BS5400/EN1337 grade meets and exceeds the requirements for materials used in the manufacture and installation of bridge bearings.
Article No. Roll Length (m) Width (mm) Thickness (mm)
Rubber sheet 2m x 1m x 5mm, as per BS5400 1001500 210005
Rubber sheet 2m x 1m x 10mm, as per BS5400 1001501 2100010
Rubber sheet 2m x 1m x 12.5mm, as per BS5400 1001502 2100012.5
Rubber sheet 2m x 1m x 15mm, as per BS5400 1001503 2100015
Rubber sheet 2m x 1m x 20mm, as per BS5400 1001504 2100020
Rubber sheet 2m x 1m x 25mm, as per BS5400 1001505 2100025
Rubber sheet 2m x 1m x30mm, as per EN1337-3 1001560 2100030


BS5400 and now EN1337 Grade Bridge Bearing Rubber does not contain any ground or recycled vulcanizes, it has good weathering resistance and is suitable for use up to 6 weeks at sub zero temperatures with occasional periods of up to 3 days below -25ºC. This product can be cut to customers size requirements

Application Guide Temp Guide

Additional Information

Colour Black
Material Natural Rubber (NR)
Hardness (Shore A) 60
Maximum Temperature (°C) 70
Minimum Temperature (°C) -25
Density (g/cm³) 1.5
Tensile Strength (MPa) 15.5
Elongation at break (%) 400
Abrasion Resistance (mm³) (DIN53516) 300.0000
*Dimensions can vary, they are typical only.

Further Information (File Downloads)
