| Maximum Load (kg) | ||||||||||
| Article No. | A |
B |
C1 |
C2 |
D |
E1 |
E2 | F |
45 Shore |
60 Shore A |
KPUM3232 |
10.0 |
32 |
19.3 |
20 |
12/13 |
10 |
10 |
32 |
40 |
113 |
KPUM3232M |
10.0 |
32 |
19.3 |
20 |
12/17.5 |
5 |
5 |
32 |
35 |
100 |
| KPUM4752 | 13.5 | 47 | 33 | 31.75 | 20 | 14 | 12 | 52.2 | 79 | 172 |
| KPUM6463 | 16.0 | 64 | 40 | 38.1 | 23 | 22 | 19 | 62 | 159 | 390 |
| KPUM9075 | 23.7 | 89 | 58.4 | 57.5 | 23 | 25 | 22 | 73 | 231 | 531 |
| Support Structure 1 | Support Structure 2 | |||||||
| Article No. | Axial Kg | Radial Kg | Fo Hz | El mm | Axial Kg | Radial Kg | Fo Hz | El mm |
KPUM3232
(45sh) |
40 |
13 |
15 |
9.5 |
40 |
13 |
15 |
9.5 |
KPUM3232 (60sh) |
113 |
22 |
15 |
9.5 |
113 |
22 |
15 |
9.5 |
| KPUM4752 (45sh) | 79 |
29 |
12 |
14 |
54 |
36 |
15 |
12.5 |
| KPUM4752 (60sh) | 172 |
75 |
12 |
14 |
118 |
81 |
15 |
12.5 |
| KPUM6463(45sh) | 159 |
63 |
11 |
22 |
68 |
47 |
15 |
25.5 |
| KPUM6463(65sh) | 390 |
175 |
11 |
22 |
147 |
111 |
15 |
25.5 |
| KPUM9075(45sh) | 231 |
104 |
10 |
28.5 |
136 |
100 |
15 |
25.5 |
| KPUM9075(65sh) | 531 |
268 |
10 |
28.5 |
227 |
181 |
15 |
25.5 |
