Type |
D |
K |
L |
H |
G |
| TH0907 |
7,2 |
9 |
9 |
2,5 |
M3 |
| TH1209 |
9,3 |
12 |
11,5 |
3 |
M4 |
| TH1510 |
10,2 |
15 |
14,5 |
3,5 |
M5 |
TH1812 |
12,7 |
18 |
17 |
4 |
M6 |
TH2416 |
16,5 |
24 |
22 |
5 |
M8 |
Type |
Clearance Hole mm |
Sheet Thickness mm |
Torque Nm | Max Load Compression (kg) | Max Load Shear (kg) | |||
| Installation type 1 | Installation type 2,3 | Installation type 1 |
Installation type 2 ,3 |
Installation type 1 | Installation type 2 ,3 | |||
TH0907 |
7.2-7.5 |
0.6-2.5 |
0.5 | 0.4 | 1 |
5 |
1 | 2.5 |
TH1209 |
9.3-9.6 |
0.8-3.3 |
0.6 | 0.5 | 1 |
7 |
1 | 3.5 |
TH1510 |
10.2-10.5 |
0.8-4.3 |
1.0 | 0.6 | 1.5 |
10 |
1.5 | 5 |
TH1812 |
12.7-13.0 |
1.5-5.0 |
3.5 | 0.9 | 3 |
14 |
3 | 7 |
TH2416 |
16.5-16.8 |
1.5-6.5 |
4.0 | 1.8 | 5 |
28 |
5 | 14 |
