Available with stainless steel or mild steel parts.
| Part No | Height (mm) | Width (Rubber) (mm) | Width (Metal) (mm) |
Length (Metal) (mm) |
Center Hole Diameter (mm) |
| KMC7566 | 67 | 64 | 92 |
105 |
15.3 |
| KMC7574 | 74 | 88 | 92 |
105 |
15.3 |
| KMC7574M20 | 74 | 88 | 92 |
105 |
20.5 |
| 45 IRHD | 60 IRHD | 70 IRHD | ||||
| Part No | Max kg's | Defln. mm | Max kg's | Defln. mm | Max kg's | Defln. mm |
| KMC7574 | 290 | 6.4 | 500 | 5.9 | 610 | 4.9 |
| KMC7566 | 200 | 6.2 | 380 | 6.0 | 525 | 5.4 |
| KMC7574M20 | 290 | 6.4 | 500 | 5.9 | 610 | 4.9 |
