TH Flexible Locator anti-vibration Mount




Flexable Locator Anti Vibration mount

Flexable Locator Anti Vibration mountings
Flexable Locator Anti Vibration mounts

Characteristics:

The mounts work in Compression (axial) and Shear (radial).

80% Reduction of Energy due to Vibration

Easy to Fix and Install


Type
D
K
L
H
G
TH0907
7,2
9
9
2,5
M3
TH1209
9,3
12
11,5
3
M4
TH1510
10,2
15
14,5
3,5
M5
TH1812
12,7
18
17
4
M6
TH2416
16,5
24
22
5
M8

Technical Data
Type
Clearance
Hole mm
Sheet Thickness mm
Torque Nm
Max Load Compression
Max Load Shear
TH0907
7.2-7.5
0.6-2.5
0.4
5
2.5
TH1209
9.3-9.6
0.8-3.3
0.5
7
3.5
TH1510
10.2-10.5
0.8-4.3
0.6
10
5
TH1812
12.7-13.0
1.5-5.0
0.9
14
7
TH2416
16.5-16.8
1.5-6.5
1.8
28
14
